Alderamin Mk5 Series
1623
.89
€
Price excl. VAT
1623
.89
€
Price excl. VAT
Azure Certified Device
Azure Edge Managed
Operating temperature
Wide operating temperature range for trouble-free operation in harsh environments.
Fanless system
Advanced passive cooling system provides fanless operation even under full load and in harsh environments.
Modular Design
Flexible CPU, storage, and expansion options for tailored systems.
Powerful Performance
Intel Core i9 and up to 64GB of memory for maximum performance.
Technical Details
Operating Systems
General data
| Power button | Yes |
| Reset button | No |
| Cooling | Fanless |
Graphics
| Graphic chip (GPU) | (i3/i5) Intel® UHD Graphics 730, (i7/i9) Intel® UHD Graphics 770 |
| HDMI | 1x |
| VGA | 1x |
| Display port | 1x |
| Amount simultaneous displays | 3x |
| Resolution max | HDMI: 4096 x 2160 @ 60Hz, DP: 7680 x 4320 @ 60Hz |
Ethernet
| Connector TX | RJ45 |
| 10/100/1000BaseTX Ports | 4x (10/100/1000/2500) |
Additional interfaces
| RS-232/422/485 | 3x |
| USB 3.0 | 8x |
| Line-out | 1x |
| Mic-in | 1x |
Expansion slots
| PCIe 16x | 1x |
Power supply
| Power supply V DC | 9-48V DC |
Physical characteristics
| Housing material | Aluminum/Steel |
| Ingress protection | |
| Dimensions (W x H x D) | 268 x 108 x 246 mm |
| Weight | 6,9 kg |
| Mounting | Wall Mount |
| Housing color | Black |
Environmental
| Operating temperature range | 35W TDP Processor: -40°C to 70°C / 65W TDP Processor: -40°C to 50°C |
| Humidity | 10% ~ 90% R/H (Non-condensing) |
| Vibration | Operating: 5Hz~500Hz / 5Grms / 3Axis (w/ SSD, according to IEC60068-2-64) |
| Shock | Operating: 50 Grms, Half-sine 11 ms Duration (w/ SSD, according to IEC60068-2-27) |
Approvals
| CE (EU) | Yes |
| RoHS | Yes |
| REACH | Yes |
| FCC | Yes |
| CPU type | i3-14100T |
| CPU cores | 4C/8T |
| Passmark | ~13.000 |
| Memory / RAM capacity | DDR5, up to 64GB |
| CPU type | i5-14400T |
| CPU cores | 10C/16T |
| Passmark | ~24.000 |
| Memory / RAM capacity | DDR5 ECC, up to 64 GB |
| CPU type | i7-14700T |
| CPU cores | 20/28T |
| Passmark | ~32.000 |
| Memory / RAM capacity | DDR5 ECC, up to 64 GB |
| CPU type | i9-14900T |
| CPU cores | 24C/32T |
| Passmark | ~40.000 |
| Memory / RAM capacity | DDR5 ECC, up to 64 GB |
Windows 10 Pro up to Version 1809
Receives security and feature updates No single function device license limitation Has individual license key 2-year update support w/o feature update
Windows 10 Pro from Version 1903
Receives security and feature updates No single function device license limitation Has individual license key 2-year update support w/o feature update
Windows 10 IoT Version LTSC 2019
Receives only security updates No incompatibility risk with feature updates Includes Unified Write Filter for hardening 5- yr (mainstream) to 10 yr (ext.) support
Windows 10 IoT Version LTSC 2021
Receives only security updates No incompatibility risk with feature updates Includes Unified Write Filter for hardening 5- yr (mainstream) to 10 yr (ext.) support
Windows 11 Pro
Windows 11 IoT
Linux Ubuntu
Windows Server Version on request
Technical Details
General data
| Power button | Yes |
| Reset button | No |
| Cooling | Fanless |
Graphics
| Graphic chip (GPU) | (i3/i5) Intel® UHD Graphics 730, (i7/i9) Intel® UHD Graphics 770 |
| HDMI | 1x |
| VGA | 1x |
| Display port | 1x |
| Amount simultaneous displays | 3x |
| Resolution max | HDMI: 4096 x 2160 @ 60Hz, DP: 7680 x 4320 @ 60Hz |
Ethernet
| Connector TX | RJ45 |
| 10/100/1000BaseTX Ports | 4x (10/100/1000/2500) |
Additional interfaces
| RS-232/422/485 | 3x |
| USB 3.0 | 8x |
| Line-out | 1x |
| Mic-in | 1x |
Expansion slots
| PCIe 16x | 1x |
Power supply
| Power supply V DC | 9-48V DC |
Physical characteristics
| Housing material | Aluminum/Steel |
| Ingress protection | |
| Dimensions (W x H x D) | 268 x 108 x 246 mm |
| Weight | 6,9 kg |
| Mounting | Wall Mount |
| Housing color | Black |
Environmental
| Operating temperature range | 35W TDP Processor: -40°C to 70°C / 65W TDP Processor: -40°C to 50°C |
| Humidity | 10% ~ 90% R/H (Non-condensing) |
| Vibration | Operating: 5Hz~500Hz / 5Grms / 3Axis (w/ SSD, according to IEC60068-2-64) |
| Shock | Operating: 50 Grms, Half-sine 11 ms Duration (w/ SSD, according to IEC60068-2-27) |
Approvals
| CE (EU) | Yes |
| RoHS | Yes |
| REACH | Yes |
| FCC | Yes |
| CPU type | i3-14100T |
| CPU cores | 4C/8T |
| Passmark | ~13.000 |
| Memory / RAM capacity | DDR5, up to 64GB |
| CPU type | i5-14400T |
| CPU cores | 10C/16T |
| Passmark | ~24.000 |
| Memory / RAM capacity | DDR5 ECC, up to 64 GB |
| CPU type | i7-14700T |
| CPU cores | 20/28T |
| Passmark | ~32.000 |
| Memory / RAM capacity | DDR5 ECC, up to 64 GB |
| CPU type | i9-14900T |
| CPU cores | 24C/32T |
| Passmark | ~40.000 |
| Memory / RAM capacity | DDR5 ECC, up to 64 GB |
Operating Systems
Windows 10 Pro up to Version 1809
Receives security and feature updates No single function device license limitation Has individual license key 2-year update support w/o feature update
Windows 10 Pro from Version 1903
Receives security and feature updates No single function device license limitation Has individual license key 2-year update support w/o feature update
Windows 10 IoT Version LTSC 2019
Receives only security updates No incompatibility risk with feature updates Includes Unified Write Filter for hardening 5- yr (mainstream) to 10 yr (ext.) support
Windows 10 IoT Version LTSC 2021
Receives only security updates No incompatibility risk with feature updates Includes Unified Write Filter for hardening 5- yr (mainstream) to 10 yr (ext.) support
Windows 11 Pro
Windows 11 IoT
Linux Ubuntu
Windows Server Version on request
Efficiency Meets Power
Alderamin Mk5 with Intel Core Processors
The fanless Industrial High-Performance Computer Alderamin Mk5 stands out with its Intel Core processor lineup, built to handle the toughest industrial applications. The system offers flexible configurations, starting with the Intel® Core™ i3-14100T processor, featuring 4 cores and 8 threads—a reliable choice for standard applications. The Intel® Core™ i5-14400T, with 10 cores and 16 threads, boosts multitasking capabilities, making it ideal for data-heavy tasks.
For more demanding applications, the Alderamin Mk5 includes the Intel® Core™ i7-14700T, with 20 cores and 28 threads, efficiently managing complex calculations and parallel workloads. Leading the lineup is the Intel® Core™ i9-14900T, a powerhouse with 24 cores and 32 threads, built to deliver unparalleled performance for high-stakes industrial needs. With its range of processor options, the Alderamin Mk5 provides adaptable, top-tier performance in a durable, fanless design built for continuous operation in challenging environments.
