Azure Edge Managed
Azure Certified Device
Fanless system
Advanced passive cooling system provides fanless operation even under full load and in harsh environments.
Operating temperature
Wide operating temperature range for trouble-free operation in harsh environments.
Technical Details
General data
| Power button | Yes |
| Reset button | NA |
| Cooling | Fanless |
Graphics
| Graphic chip (GPU) | Intel® UHD Graphics |
| HDMI | 1x HDMI 1.4 |
| Display port | 1x Display Port 1.4 |
| Amount simultaneous displays | 2 |
| Resolution max | 4096 x 2160@60Hz |
Ethernet
| Connector TX | RJ45 |
| 10/100/1000BaseTX Ports | NA |
| 10/100/1000/2500BaseTX Ports | 2x |
Additional interfaces
| RS-232/422/485 | NA |
| RS232 | 1x |
| USB 2.0 | 2x |
| USB 3.0 | 3x USB 3.2 Gen 2 Type A |
| USB C | Support PD15W, 5V/3A, DP Alt mode, USB3.2 Gen1 |
| Line-out | 1x |
| Mic-in | NA |
Expansion slots
| PCIe 16x | NA |
| 1 x M.2 2242/3042/3052 B Key (USB2.0/PCIe x1/SATAIII) | |
| 1x M.2 2280 M key (PCIe x4, SATAIII) | |
| 1 x M.2 2230 E key (PCIeX1, USB2.0) |
Power supply
| Power supply V DC | 8 - 26VDC |
Physical characteristics
| Housing material | Steel/Aluminium |
| Ingress protection | NA |
| Dimensions (W x H x D) | 171 x 57 x 133mm |
| Weight | 2.1 Kg |
| Mounting | Wall Mount / DIN Rail (optional) |
| Housing color | Black |
Environmental
| Operating temperature range | -40°C to 60°C |
| Humidity | 10% - 95%, not condensating |
| Vibration | 5Hz~500Hz / 2Grms / 3Axis (w/ SSD, according to IEC60068-2-64) |
| Shock | 50 Grms, Half-sine 11 ms Duration (w/ SSD, according to IEC60068-2-27) |
Approvals
| CE (EU) | Yes |
| RoHS | Yes |
| REACH | Yes |
| FCC | Yes |
CPU
| CPU type | Intel® Processor N97 |
| CPU cores | 4C/4T |
| Passmark | ~5300 |
| Memory / RAM capacity | up to 16GB DDR5 |
Approvals
| CE (EU) | Yes |
| RoHs | Yes |
| REACH | Yes |
| FCC | Yes |
| ICES | Yes |
