IoT Edge Computing Gateway for Azure IoT Hub EG600 Mk2

Welotec EG603W Mk2

WEG600100040

Fanless

DIN-Rail

Model with Intel Atom® x6413E and 8GB RAM. Combines various interfaces and allows for simultaneous use of LTE and WiFi
Fully integrated with Azure IoT Hub and Azure IoT Edge support. AWS integration via container
Azure Device Provisioning Service (DPS) with TPM
Integrated container runtime and Docker Compose support
Integrated firewall, routing, NAT, OpenVPN
Optional 4G LTE, 5g RedCap on request and WiFi connectivity

Connection:

Non-wireless

4G LTE

869

.00

€

Price excl. VAT

Docker

Azure Edge Managed

Azure Certified Device

Cloud integration

Seamless cloud integration for distributed computing and deployment.

4G LTE and 5G

Optional 4G/LTE and 5G ensure high data rates and optimal network coverage.

Container applications

Reliably develop and deploy container-based applications.

TPM

Integrated Trusted Platform Modul for secure device provisioning and authentication.

Security

Integrated firewall for the highest security standards.

Operating System

Software environment for flexible data processing and storage.

Device Management

Easy rollout of VPN configurations and certificates to connected Welotec devices (incl. Docker Container).

Wi-Fi connectivity

Optional IEEE 802.11n WiFi connectivity.

Edge computing

Easy and scalable system for applications directly at the Edge.

Technical Details

General Information


Type	Edge Computing Gateway
Series	EG600

Software


Operating system info	Welotec egOS: hardened Linux operating system based on Yocto with no root access for users. Optional with HMI functionality
Application deployment	Docker CLI, Docker compose, Moby Engine, Azure Edge Runtime
Security	Integrated firewall, TPM 2.0 (function Azure DPS), no root access for users, signed firmware images (with egOS 1.5 and higher)
Network	Routing, NAT, 4G LTE Cellular Mangament, Wifi Client support, Interface Management
Cloud Compatibility	Azure IoT Edge 1.4 and higher (native in OS) Azure IoT Hub Azure DPS, AWS Greengrass 2.0 (via Container)

Configuration


Remote configuration	SMART EMS for configuration management, OTA firmware upgrade, certificate management
Remote access	VPN Security Suite for remote access and maintenance for the device and connected endpoint devices like PLC, HMI, IPC and more
Local	CLI via serial or SSH, local web interface for configuration (device onboarding in restricted company networks)

Hardware


CPU	Intel Atom® x6413E
RAM	8 GB
Free Storage for Container and Data	100 GB free storage; optional: expandable up to 1 TB
TPM	TPM 2.0
Gigabit Ethernet	3x 2,5GbE
USB	3x USB 3.0, 1x USB 2.0
Serial	1x RS-232, 1x 485
Display	1x HDMI, 1x Display

Power Supply


Power Supply (EU)	WIPC05000084
Input Voltage	12 - 36 V DC (+/- 10%)
Connector	4 PIN terminal block

Physical characteristics


Housing material	Steel / Aluminum
Ingress Protection	IP20
Dimensions	140 mm (H) x 92 mm (D) x 64 mm (W)
Dimensions with DIN rail	150mm (H) x 112mm (D) x 64mm (W)
Weight	830 g
Mounting	DIN rail mount

Environmental


Operating temperature	-20 - +70 °C
Humidity	5 – 95 % (non-condensing)
Storage temperature	-40 - +85 °C

Approvals


CE (EU)	Yes
RoHS	Yes
REACH	Yes
FCC	Yes
ICES	Yes

Technical Details

General Information


Type	Edge Computing Gateway
Series	EG600

Software


Operating system info	Welotec egOS: hardened Linux operating system based on Yocto with no root access for users. Optional with HMI functionality
Application deployment	Docker CLI, Docker compose, Moby Engine, Azure Edge Runtime
Security	Integrated firewall, TPM 2.0 (function Azure DPS), no root access for users, signed firmware images (with egOS 1.5 and higher)
Network	Routing, NAT, 4G LTE Cellular Mangament, Wifi Client support, Interface Management
Cloud Compatibility	Azure IoT Edge 1.4 and higher (native in OS) Azure IoT Hub Azure DPS, AWS Greengrass 2.0 (via Container)

Configuration


Remote configuration	SMART EMS for configuration management, OTA firmware upgrade, certificate management
Remote access	VPN Security Suite for remote access and maintenance for the device and connected endpoint devices like PLC, HMI, IPC and more
Local	CLI via serial or SSH, local web interface for configuration (device onboarding in restricted company networks)

Hardware


CPU	Intel Atom® x6413E
RAM	8 GB
Free Storage for Container and Data	100 GB free storage; optional: expandable up to 1 TB
TPM	TPM 2.0
Gigabit Ethernet	3x 2,5GbE
USB	3x USB 3.0, 1x USB 2.0
Serial	1x RS-232, 1x 485
Display	1x HDMI, 1x Display

Power Supply


Power Supply (EU)	WIPC05000084
Input Voltage	12 - 36 V DC (+/- 10%)
Connector	4 PIN terminal block

Physical characteristics


Housing material	Steel / Aluminum
Ingress Protection	IP20
Dimensions	140 mm (H) x 92 mm (D) x 64 mm (W)
Dimensions with DIN rail	150mm (H) x 112mm (D) x 64mm (W)
Weight	830 g
Mounting	DIN rail mount

Environmental


Operating temperature	-20 - +70 °C
Humidity	5 – 95 % (non-condensing)
Storage temperature	-40 - +85 °C

Approvals


CE (EU)	Yes
RoHS	Yes
REACH	Yes
FCC	Yes
ICES	Yes

Integrated Edge

Welotec egOS – Operating System

All Welotec edge gateways are fully integrated with an operating system, creating a homogeneous layer for managing and deploying edge applications with a high level of security.

The egOS is a Linux-based operating system specifically designed for scalable edge applications and robust IT security. Its constant reliability and security are maintained through regular updates and upgrades. The system is optimized for cloud connectivity and container deployment. As an open platform, egOS supports customized solutions and facilitates software-driven innovation.

Discover our productivity solutions

Ready to use and scale

Azure Cloud

Our edge gateways bring cloud logic to the edge. With the fully integrated Azure IoT Edge Runtime, users can leverage Azure services and deploy applications directly from the cloud with just a few clicks. See the benefits at a glance:

Easily transfer data for cloud development
Local deployment of cloud intelligence
Device provisioning service for device rollout, with TPM 2.0
Flexible protocol selection for bi-directional data communication (MQTT, AMQP, Websocket)
